R46 MX Tune | LSC

Name: R46 MX Tune | LSC
Brand: Sirris Store
SKU: 246-99-007-LTE-XX RR SHOCK, SURRON UB AM, 46MM, 320MM X 84.2MM, MX, LTE
Price: 899.0 USD
Availability: InStock

$899.00 USD

Sale Sold out

Tax included.

Rider Weight Range Light (120-160 lb) Medium (160-200 lb) Heavy (200-240 lb) X Heavy (240-280 lb) XX Heavy (280-320 lb)

Tune MX

Damper Adjust LSC

Product variants

Quantity

MX Tune is a motocross specific tune with balance, control, and bottoming resistance for the fastest speeds. It's firm suspension for maximum control and support for huge jumps, whoops and fast cornering. If you select the EBMX or MX spec, you’ll compromise a bit of trail plushness for improved bottoming resistance.

RIDER WEIGHT SPECS:

Sirris offers five weight ranges to choose from when selecting your MX Tune R46 shock. (Listed weight ranges are rider weight without riding gear on. 15 pounds of riding gear is calculated into the weight ranges)

120 lbs - 160 lbs (Light ships with 85 N/mm spring)
160 lbs - 200 lbs (Medium ships with 95 N/mm spring)
200 lbs - 240 lbs (Heavy ships with 105 N/mm spring)
240 lbs - 280 lbs (X Heavy ships with 115 N/mm spring)
280 lbs - 320 lbs (XX Heavy ships with 115 N/mm spring)

PRODUCT SPECS:

Architecture
Piggyback, steel spring

Stroke
85 mm

Length
320 mm

Weight
3.9 lbs / 1.76 kg without spring

Piston
High flow Ø46 mm, CNC 6061 billet aluminum, type 3 hard anodized coating

Piston band
Hard band

Shaft
Ø16 mm OD chrome-plated, induction hardened steel, hollow, Ø 5.5 mm ID

Shock body
Seamless 6061 aluminum, type 3 hard anodized coating, ACME thread

Spring retainer
Seamless 6061 aluminum, type 3 hard anodized coating, ACME thread, with locking feature, manual adjust

Bottom out
MCU bumper

Top out
Rubber bumper
